Product Details

Specification:

1、Total Size:1135X530X200mm

2、Display size:768X384mm

3、Pixel density:96X48

4、Working voltage:12VDC

5、Working current :<10A(LED strobe lights on)

6、Display module:P8 outdoor full color 256X128mm

7、Gray level:256

8、Displayable content type:Text, Letters, Pictures

9、Control mothod :Wired controller

10、Program mothod:PC software

11、Writing mothod:U Disk

12、Operating temperature:-30℃ to 50℃

13、IP rate:IP65

14、Weight:30KG

15、Warranty period:1 year



Features:

1、Outdoor highlight P8 full color LED module.

2、Wire controller with synchronize display.

3、256 level grayscale display.

4、Designed with protection mechanism, during LED display rise up or drop down process, to press any button on controller, LED display will stop action, to well protect operator and equipment itself.

5、Designed with LED Stroble moudle around the base frame, red X 7 and blue X 7, can be work as lightbar.

6、IP rate: IP65
